Measure the energy loss of a rolling tire to determine its contribution to vehicle energy efficiency and range. Major manufacturers and test laboratories worldwide trust MTS Rolling Resistance systems to meet their testing requirements. MTS offers a flexible array of rolling resistance configurations to meet your unique testing demands.
Leading automotive and tire manufacturers trust MTS to provide deep insights along with the most accurate and repeatable results for their tire testing requirements
Leveraging decades of custom engineering and design, MTS Rolling Resistance systems maximize sensitivity, repeatability and reliability
Local MTS service expertise and life cycle management means a quick response with immediate troubleshooting to ensure system uptime
The MTS Rolling Resistance family comprises three standard configurations plus customizable options to meet a wide range of testing and production needs
|
Units |
Passenger Car & Light Truck |
Commercial Truck |
|
|
Roadwheel Diameter |
mm |
1708 or 2000 |
1708 or 2000 |
|
Roadway Maximum Velocity |
km/h |
160, 250, or 320 |
160, 250, or 320 |
|
Tire Maximum Diameter |
mm |
1010 |
1400 |
|
Tire Maximum Width |
mm |
450 |
610 |
|
Radial Load |
N |
15000 or 20000 |
60000 |
|
Fx Calibrated Range |
± N |
500 |
1250 |
|
Drum Torque Calibrated Range |
± Nm |
900 |
900 |
