Metric Units | | | | | | |
MODEL NUMBER | GAGE LENGTH | MEASURING RANGE (% STRAIN) | MAXIMUM TEMPERATURE | CONTACT FORCE | CERAMIC EXTENTION RODS INCLUDED | PART NUMBER |
632.50F-08 | 10 mm | +20%/-10% | 1200°C | 780 g | Qty 4, V-chisel Edge Rods, 3.50 mm (.138 in) rod diameter 85 mm (3.35 in) long | 047-402-5381 |
632.54F-11 | 12 mm | +20%/-10% | 1200°C | 100 g | Qty 4, V-chisel Edge Rods, 2.0 mm (.0787 in) rod diameter 85 mm (3.35 in) long | 047-404-3041 |
| 632.53F-14 | 12 mm | +20%/-10% | 1200°C | 260 g | Qty 4, V-chisel Edge Rods, 3.50 mm (.138 in) rod diameter 85 mm (3.35 in) long | 047-404-1041 |
632.53F-14 | 12 mm | +20%/-10% | 1200°C | 300 g | Qty 4, V-chisel Edge Rods, 3.50 mm (.138 in) rod diameter 85 mm (3.35 in) long | 047-404-1051 |
632.53F-14 | 12 mm | +20%/-10% | 1200°C | 400 g | Qty 4, V-chisel Edge Rods, 3.50 mm (.138 in) rod diameter 85 mm (3.35 in) long | 047-404-1061 |
632.50F-04 | 12 mm | +20%/-10% | 1200°C | 780 g | Qty 4, V-chisel Edge Rods, 3.50 mm (.138 in) rod diameter 85 mm (3.35 in) long | 047-402-5391 |
632.54F-11 | 25 mm | +10% / - 5% | 1200°C | 100 g | Qty 4, V-chisel Edge Rods, 2.0 mm (.0787 in) rod diameter 85 mm (3.35 in) long | 047-404-3031 |
| 632.53F-11 | 25 mm | +20% / -10% | 1200°C | 260 g | Qty 4, V-chisel Edge Rods, 3.50 mm (.138 in) rod diameter 85 mm (3.35 in) long | 047-404-1101 |
| 632.53F-11 | 25 mm | +10% / -5% | 1200°C | 300 g | Qty 4, V-chisel Edge Rods, 3.50 mm (.138 in) rod diameter 85 mm (3.35 in) long | 047-404-1111 |
| 632.53F-11 | 25 mm | +10% / -5% | 1200°C | 400 g | Qty 4, V-chisel Edge Rods, 3.50 mm (.138 in) rod diameter 85 mm (3.35 in) long | 047-404-1121 |
632.50F-01 | 25 mm | +15%/-15% | 1200°C | 400 g | Qty 2, V-chisel Edge Rods, 3.50 mm (.138 in) rod diameter 94 mm (3.7 in) long | 047-402-5481 |
| | | | | | |
US Customary Units | | | | | | |
MODEL NUMBER | GAGE LENGTH | MEASURING RANGE (% STRAIN) | MAXIMUM TEMPERATURE | CONTACT FORCE | CERAMIC EXTENTION RODS INCLUDED | PART NUMBER |
632.54E-14 | 0.50 in | +20% / -10% | 2200°F | 100 g | Qty 4, V-chisel Edge Rods, 2.0 mm (.0787 in) rod diameter 85 mm (3.35 in) long | 047-404-3021 |
| 632.53E-14 | 0.50 in | +20%/-10% | 2200°F | 260 g | Qty 4, V-chisel Edge Rods, 3.50 mm (.138 in) rod diameter 85 mm (3.35 in) long | 047-404-1011 |
632.53E-14 | 0.50 in | +20%/-10% | 2200°F | 300 g | Qty 4, V-chisel Edge Rods, 3.50 mm (.138 in) rod diameter 85 mm (3.35 in) long | 047-404-1021 |
632.53E-14 | 0.50 in | +20%/-10% | 2200°F | 400 g | Qty 4, V-chisel Edge Rods, 3.50 mm (.138 in) rod diameter 85 mm (3.35 in) long | 047-404-1031 |
632.50E-04 | 0.50 in | +20%/-10% | 2200°F | 780 g | Qty 4, V-chisel Edge Rods, 3.50 mm (.138 in) rod diameter 85 mm (3.35 in) long | 047-402-5251 |
632.54E-14 | 1.00 in | +10%/-5% | 2200°F | 100 g | Qty 2, V-chisel Edge Rods, 2.0 mm (.0787 in) rod diameter 85 mm (3.35 in) long | 047-402-3011 |
| 632.53E-11 | 1.00 in | +10%/-5% | 2200°F | 260 g | Qty 4, V-chisel Edge Rods, 3.50 mm (.138 in) rod diameter 85 mm (3.35 in) long | 047-404-1071 |
| 632.53E-11 | 1.00 in | +10%/-5% | 2200°F | 300 g | Qty 4, V-chisel Edge Rods, 3.50 mm (.138 in) rod diameter 85 mm (3.35 in) long | 047-404-1081 |
| 632.53E-11 | 1.00 in | +10%/-5% | 2200°F | 400 g | Qty 4, V-chisel Edge Rods, 3.50 mm (.138 in) rod diameter 85 mm (3.35 in) long | 047-404-1091 |
632.50E-01 | 1.00 in | +15%/-15% | 2200°F | 400 g | Qty 4, V-chisel Edge Rods, 3.50 mm (.138 in) rod diameter 94 mm (3.7 in) long | 047-402-5471 |
1 Mount is not required when using with 653.xxB furnace, for other installations contact MTS |
